ANTENAS YAGI 10M TV
The beam can be rotated with a small TV rotator, pay attention on the relativly soft boom when tightening the boom-to-mast-clamp.
ANTENAS YAGI 10M PORTABLE
The result is a directional antenna, providing excellent mono band results and an additional use as portable or fieldday antenna is possible. Signals are about '2 S units' better than the original antenna a GPA30 (triband vertical by Fritzel) using the Icom IC-751.Ī very good alternative to a completly homebrewed antenna. He is very satisfied with the performance. With gamma match bracket 150mm outside the end of inner tube. Output from a 3-500 for a while and it did a fine job.įed with up to 1200W without any problems. (AirCell 2000) with less than 0.4 dB of loss on the 22m run. The feedline I use is a low-loss UHF cable
Putting the antenna virtually to a higher position.
This is indeed not very high, but the surrounding terrain descents in most directions The antenna is installed at about 9 m above It does not perform as our "pile-up-cracker"ĭoes, but I feel it works better than a tribander. Contacts were made withĪll continents using my TS690 with about 90 Watts output. The antenna is up since October 1998 and performance is good. The Satellite and FM portion can be used with an additional tuner (although with bad F/R ) This measurements give you a coverage of 28 - 29 MHz. The outer 8mm tubes were here shortened by the following amount: Element These are the original lengths of the gamma match, resulting in an VSWR of 1,1 at 28,65 Using the original datas for mainly SSB operation. The end tube looks out 220mm out of the inner tube and the bracket is positioned 150mm from the end of the tube. Position of the gamma match as approximately moving the bracket as far inside as possibleĪnd the inner conductor "looks out" by 70 mm at the end. The measurements used by Christoph, DF9CY: The antenna will be fed with the classic gamma matching system. Maybe the connector should be replaced by a better one. Watch the DE holder with the SO-239 socket. Here we are with a shiny new 10m beam at QTH de DK9TG The original ones by some higher quality stainless steel (VA) to avoid rusty junctions. If you are using screws you should replace Segment and fix the 8mm tube with a hose clamp. The end of the element for use with phillips screws/metal screw or you can slice the middle Just pull back the outer aluminium tube and redrill another fixing hole 4 cm nearer The tuning resulted in a shortening of 4cm of every element half.
.jpg "antenas yagi 10m")
Weight 4.7 kg Electrical datas (YO 6.58 de K6STI)į/R: 20 db 28 MHz 15 db 28.8MHz, peak of 23.5 dB MHz
ANTENAS YAGI 10M SOFTWARE
He redesigned the antenna using the software EZNEC and the results are quite good.īasically it can be used at the lower portion of 10m (CW/SSB part) using the measurementsĪnother report about this antenna was doneīy Martin, DK7ZB in the magazin Funkamateur issue 8/2000 (german language). During that time I searched the web and found the sameĪntenna already used and modified for ham purpose at:Ĭhristoph already used this antenna since nearly 1 year and was very satisfied with the Purchased the beam after a short check of the datas. Yagi-Uda beam antenna originally produced for CB use. 10m 3ele yagi A Converted CB Yagi-Uda Antenna for the 10-m-bandĪ local ham, Manfred, DK9TG recently found a very attractive ad of a 3ele
